UPC311G2-T1

votlage comparator, SOP8, -0.3 to 36V, 350mW, 10sec, 250nA

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.10~0.15 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.10~0.15

PartNumber:: UPC311G2-T1

Brand:: NEC - Nec | Pack: SOP | D/C: 05+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. Bill's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-03-22

From Other Seller

Part Number:UPC311G2-T1
US $0.10 - 0.15
ECA1HHG4R7

US $10.00 - 10.00 / Piece
(0) Remove
SLA4060

US $0.80 - 1.20 / Piece
(0) Remove
Quantity:

piece

Product Summary

The UPC311G2-T1 is a votlage comparator that has input currents more than a hundred times lower than devices like conventional standard type of 710. The UPC311G2-T1 is also designed to operate over a wide range of supply voltages; from ±15V op amp supplies down to the single 5V supply used for IC logic. Its output is compatible with HNIL, DTL and TTL as well as MOS circuits.

Parametrics

UPC311G2-T1 absolute maixmum ratings: (1)voltage between V+ and V-, V+-V-: -0.3 to 36V; (2)differential input voltage, VID: ±30V; (3)input voltage, VI: V--0.3 to V++0.3V; (4)output to negative supply voltage, VO-V-: -0.3 to 40V; (5)ground to negative supply voltage, VGND-V-: -0.3 to 30V; (6)power dissipation, PT: 350mW; (7)output short circuit duration: 10sec; (8)operating temperature range, Topt: -20 to 80℃; (9)storage temperature range, Tstg: -55 to 125℃.

Features

UPC311G2-T1 features: (1)operate from single 5V supply; (2)maximum input current: 250nA; (3)maximum offset current: 50mA; (4)fast ransient response: 200ns typ.
