Product Summary
The C1005X7R1C103KT is a multilayer ceramic chip capacitor.
Parametrics
C1005X7R1C103KT absolute maximum ratings: (1)Capacitance: 0.01 uF; (2)Tolerance: 10 %; (3)Voltage Rating: 16 Volts; (4)Operating Temperature Range: - 55 to + 125℃; (5)Temperature Coefficient / Code: X7R; (6)Package / Case: 0402 (1005 metric); (7)Product: General Type MLCCs; (8)Packaging: Reel; (9)Dimensions: 0.05 mm W x 1 mm L x 0.5 mm H; (10)Series: C; (11)Standard Pack Qty: 10000.0; (12)Termination Style: SMD/SMT.
Features
C1005X7R1C103KT features: (1)An electrostatic capacity has been obtained that reaches the electrolytic capacitor range through precision technology that enables the use of multiple thinner ceramic dielectric layers; (2)Since these capacitors are composed of only ceramics and metals and have a monolithic structure, they offer a long service life and high reliability; (3)Low ESL and excellent frequency characteristics allow for a circuit design that closely conforms to theoretical values; (4)Low self-heating and high ripple resistance due to low ESR.
Diagrams
 |
