Product Summary
The MAX485ESA is a low-power transceiver. It is designed as one kind of ±15kV ESD-protected, slew-rate-limited, low-power, RS-485/RS-422 transceiver device that can be used in wide range of applications such as (1)low-power RS-485 transceivers; (2)low-power RS-422 transceivers; (3)Level translators; (4)transceivers for EMI-sensitive applications; (5)industrial-control local area networks. Also this device features reduced slewrate drivers that minimize EMI and reduce reflections caused by improperly terminated cables.
Parametrics
MAX485ESA absolute maximum ratings: (1)Supply Voltage (VCC): 12V; (2)Control Input Voltage (RE, DE): -0.5V to (VCC + 0.5V); (3)Driver Input Voltage (DI): -0.5V to (VCC + 0.5V); (4)Driver Output Voltage (A, B): -8V to +12.5V; (5)Receiver Input Voltage (A, B): -8V to +12.5V; (6)Receiver Output Voltage (RO): -0.5V to (VCC +0.5V); (7)Continuous Power Dissipation (TA = +70℃); (8)8-Pin Plastic DIP (derate 9.09mW/℃ above +70℃): 727mW; (9)14-Pin Plastic DIP (derate 10.00mW/℃ above +70℃): 800mW; (10)8-Pin SO (derate 5.88mW/℃ above +70℃): 471mW.
Features
MAX485ESA features: (1)For Fault-Tolerant Applications; (2)For Space-Constrained Applications; (3)For Multiple Transceiver Applications; (4)For Fail-Safe Applications; (5)For Low-Voltage Applications.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 MAX485ESA |
Maxim Integrated Products |
RS-422/RS-485 Interface IC |
Data Sheet |
Negotiable |
|
||||||||||||
|
MAX485ESA+ |
Maxim Integrated Products |
RS-422/RS-485 Interface IC RS-485/RS-422 Transceiver |
Data Sheet |
|
|
||||||||||||
|
MAX485ESA+T |
Maxim Integrated Products |
RS-422/RS-485 Interface IC RS-485/RS-422 Transceiver |
Data Sheet |
|
|
||||||||||||
 |
MAX485ESA-T |
Maxim Integrated Products |
RS-422/RS-485 Interface IC |
Data Sheet |
